YABO 51.2V 300Ah Lithium Iron Phosphate Rack-mounted Solution
UT48300L-2
Specification：
1. Brand: YABO
2. Capacity: 51.2V 300Ah Rack-mount LiFePO4 Battery
3. Battery Type: LiFePO4 Battery/lithium Battery
4. Output Power Range: 5~10 kWh
5. Warranty: 5 years
6. Weight: Approx. 121Kg
7. Cycle life: 6000cycles
8. Dimension: 482.6*735*245（5.5U）
9. System Type: Rack-mounted
10. Application: Home Energy Storage, RV, Tower Base Station
1. Brand: YABO
2. Capacity: 51.2V 300Ah Rack-mount LiFePO4 Battery
3. Battery Type: LiFePO4 Battery/lithium Battery
4. Output Power Range: 5~10 kWh
5. Warranty: 5 years
6. Weight: Approx. 121Kg
7. Cycle life: 6000cycles
8. Dimension: 482.6*735*245（5.5U）
9. System Type: Rack-mounted
10. Application: Home Energy Storage, RV, Tower Base Station
Quantity
1.The Description of Lithium Iron Phosphate Rack-mounted Solution:
Nominal Voltage | 48V |
Nominal Capacity | 300Ah |
Size (L*W* H) | 482.6*735*245mm |
Weight | 121kg |
Electric Energy | 15360 Wh |
Cycle Life | 6000 times ,80% DOD |
Maximum Parallel Quantity | 15PCS (48V 176.64Kwh) |
Warranty | 5 years |
Ambient Temperature | - 15 ~ 5 5℃ , > 4 5℃ |
Communication Interface | RS485/CAN / RS232/ Dry contact |
Certificate | ISO9001,CNAS,CE,ROHS,FCC,MSDS,UN38.3,IEC,BIS,CB |
Product Name | 51.2V 300Ah Lithium Iron Phosphate Rack-mounted Solution |
Application | Household energy storage, integrated base stations, etc. |
2.The Advantage of Lithium Iron Phosphate Rack-mounted Solution:
YaBo Power's Lithium Iron Phosphate Rack-mounted Solution is an efficient and reliable household and commercial energy storage solution.Using advanced lithium iron phosphate technology, the battery provides excellent safety, thermal stability and a cycle life of more than 6,000 times, even at a depth of discharge (DoD) of 80%. It also performs well. Its lifepo4 48v system voltage ensures compatibility with various inverters and energy management systems, flexible design and easy integration.The rack-mounted design optimizes the use of space and makes installation simple and fast.The powerful battery management system (BMS) provides comprehensive real-time monitoring and protection functions to effectively prevent overvoltage, overcurrent and overheating, and ensure that the rack mount battery is always running stably.WhetherLithium Iron Phosphate Rack-mounted Solution is used for energy storage in solar systems, backup power supply, or load transfer, the battery is an ideal choice for households and businesses pursuing reliable and environmentally friendly energy solutions.
